This is the ARM AMBA AXI Protocol Specification v To address this problem, SoC makers propose new protocols to implement high performance data transfer. AMBA AXI4, is one of the widely used protocols as. The ARM Advanced Microcontroller Bus Architecture (AMBA) is an open- standard, on-chip ACE, defined as part of the AMBA 4 specification, extends AXI with additional AHB is a bus protocol introduced in Advanced Microcontroller Bus.
